Server Topology
Server Topology shows the overview of servers in the replication process.   This form also shows number of transactions in the replication queue.

Note
  1. Different colour codes is used to reflect the replication status.
  2. Out Rate is the rate in minutes data is replicating to other servers.
  3. Out TTS (Time to Settle) is the rate in minutes for the data to settle.
  4. Status shows if the server is Online or Offline.
Figure 1: Server Topology
